Super73 ZX E-Bike

SUPER73 ZX E-BIKE

The SUPER73 ZX Electric Bike is for anyone looking to eletrify their ride. This bike features a lighter aircraft-grade aluminum frame an removable vattery. It has improved ergonomics with a more upright riding postion and is one of the most comfortable SUPER73’s to date. This electric motorbike doesn’t require a license, insurance, or registration, so anyone can ride it. It comes with a battery that you can easily charge with any 110v outlet and a removable key that makes it easy to charge at home and in-between rides. This bike has a slightly toller seat height and larger battery making this bike the perfect step up from the Z1. It come standard with the LZRD modern street tires that were designed with micro knurling to improve cornering group and has extended range and treadlife, making these tires super long lasting. The SUPER73 ZX Electric Bike is perfect for your daily commute, or cruising around time.

FEATURES

• Multi-Class Ride Modes
• Throttle Operation + Pedal Assist
• 3 Additional Ride Modes Available
• Legally Ride Without a License, Insurance or Registration
• Built-In Turn-by-Turn Navigation
• Get Directions to Your Route
• Displays on Mobile Device & Smart Display
• iOS and Android Compatible
• Over-the-Air Updates
• 30+ Miles of Range at 20 mph Under Throttle-Only Operation
• 50+ Miles of Range Using ECO Pedal Assist Mode
• Durable 615 watt-hour Battery
• Poweful DC Hub Motor
• Internally Geared Brushless Motor
• Up to 1200 Watts Peak Power

TECH SPECS

Performance

• Motor:
• Class-1 Mode Output – 750 watts Nominal / 1200 watts Peak
• Class-2 Mode Output – 750 watts Nominal / 1200 watts Peak (Default)
• Class-3 Mode Output – 750 watts Nominal / 1200 watts
• Unlimited Mode Output – 750 watts Nominal / 1200 watts Peak
• Top Speed:
• Class-1 Mode – up to 20 mph (Throttle Deactivated, Pedal (Assist Only)
• Class-2 Mode – up to 20 mph
• Class-3 Mode – up to 28 mph (Throttle Deactivated, Pedal-Assist Only)
• Unlimited Mode – Up to 28 mph
• Battery: 615 watt-hours, 18650 Cells
• Charger: 2A
• Charge Time: 6-7 Hours
• Throttle: Thumb Throttle
• Display: Transflective Monochrome LCD + Mobile Device
• Pedal Assist: 4 Modes (ECO, TOUR, SPORT, SUPER)

Dimensions

• Vehicle Weight: 63 lbs
• Length x Width x Height: 68″ x 27.5 x 42″
• Rider Weight Limit: 325 lbs
• Seat Height: 31″

Frameset

• Frame: 6061 / 7005 Aluminum Alloy, 1-1/8″ to 1.5″ Tapered Head Tube
• Front Hub: 9 mm x 135 mm, Steel Axle
• Rims: 20″ x 100 mm Alloy, Lightening Cutouts
• Front Tires:
• Moon Rock, Storm Grey – 20″ x 4″ LZRD
• Agave, Ron Burgundy, Panthro Blue – 20″ x 4.5″ LZRD
• Rear Tires:
• Moon Rock, Storm Grey – 20″ x 4″ LZRD
• Agave, Ron Burgundy, Panthro Blue – 20″ x 5″ LZRD
• Inner Tubes: 20″ x 4.5″-5″, Angled Valve Stem
• Brakes: Mechanical
• Rotors: 180 mm / 180 mm
• Bottom Bracket: 120 mm Sealed Bearing, Square Taper
• Crank: 25 mm Alloy
• Chain Ring: 36T
• Gearing: Single Speed, 16T Rear Cog
